8000W Bicycle Motor

Motor solution for electric Bike, Bicycle, Motorbike, Motorcycle.

The advantage of 8000W Bicycle Motor
1) High Efficiency. The efficiency is up to 85% to 91%, save battery power, one charge can run more distance.
2) High Speed. Speed up your Bicycle or Motorcycle to reach max. 140km/h.
3) High Voltage. Ranges from 48V to 96V. High voltage, low current, no hot, protect motor.
4) This bicycle motor is applied to rim (hub) size from 17 inch to 26 inch.
5) The standard configuration is 36 spoke holes.
6) The axle length and diameter can be customized.
7) Customized trademark and logo.
8) 2 sets hall sensor, 1 for use and 1 for backup, low repair rate.
Let your Bicycle/Motorcycle have a strong core, go wild.

8000W Bicycle Motor (273) for electric Bike, Bicycle, Motorcycle.
1) Motor Type: DC Brushless Motor
2) Version: V2, V3
3) Rated Power (Continuous Power): 8000W.
4) Max. Power: 12800W (peak 16000W).
5) Voltage: 72V (option 72V-120V).
6) Magnet Height: 50mm.
7) Motor Poles: 16 Pairs.
8) Recommendation Rim: 18inch – 26inch
9) Max. Speed: 30 – 140km/h
10) Max. Torque: 50 – 266N.m
11) Brake: disc brake (220mm)
12) Dropout: 200mm
13) Hall Sensor: 2 sets (1 for use and 1 for backup)
14) Max. Working Termperature: 70 ℃ (peak 120℃ in 5 – 10 second)
15) Waterproof Grade: IP54
16) Color: Black
17) Net Weight: 20.0kgs
18) Unit Packing Size: 43x43x34cm/carton

Advice on Motor Speed

1) The max. speed of 8000W bicycle motor ranges from 70km/h to 140km/h.
2) The recommend max. speed is 110km/h at battery voltage 72V. The repair rate is the lowest at this speed configuration.
3) The speed of motor will go up when the battery voltage increases.
4) It is better to advise your battery voltage and your expected speed. And we can recommend the correct speed version of this motor to you.
5) This 8000W bicycle motor (spoke motor) is the perfect solution for racing motorbike and motorcycle.

Motor Speed Version

1) Torque Version, 3T, WP80030X, 880rpm at 72V.
2) Balance Version, 2T+, WP80029X, 1170rpm at 72V.
3) Fast Version, 2T, WP80020X, 1400rpm at 72V.
This 8000W Bicycle Motor (Spoke Motor) can run at voltage 48V-96V (max. 120V), the recommend voltage is 72V. The rotating speed increases proportionally with the increase of voltage.

Advice on Motor Controller

1) You should choose 130-200A (power current limited) controller for this 8000W Bicycle Motor (spoke motor).
2) This 8000W bicycle motor can support both Trapezoidal Type and Sinusoidal Type controllers.
3) The recommended controller are Kelly Controller KLS96601, APT Controller 96600, LB Controller 72502 and other brands.
4) Please feel free to contact us if you have no idea of how to choose the matching controller. We will behind you all the way.

Please Click Here Bicycle Motor for more motors in different power and size.

Drawing of 8000W Bicycle Motor
